Features

• ●Powered by constant‑pressure compressed air, delivering ample output torque and configurable clockwise/counter‑clockwise rotation
• ●Built‑in continuously‑variable‑transmission mechanism for convenient manual speed regulation
• ●Boasts dependable operation, steady liquid‑delivery flow, high torque output and quiet‑running performance; compatible with multiple specifications of pump heads and peristaltic tubing

• ●Supports prolonged non‑stop operation and effortless upkeep. Its stainless‑steel casing provides outstanding safety and explosion‑proof capacity. ●Well‑adapted to multiple‑purpose industrial environments, particularly work‑sites containing flammable gas and demanding explosion‑proof equipment.

• Product Features

• • •Pneumatic‑driven design with excellent explosion‑proof safety. Ideal for electrically‑hazardous locations and sites with no available power source
  • •Low‑heat output and minor temperature increase during running
  • •150‑W low‑upkeep pneumatic motor with high‑torque output; stepless speed control realized by manually tuning the air‑flow valve
  • •Supports start‑stop control and forward‑reverse rotation switching
  • •The three‑way assembly features a rotatable structure. It can be pivoted outward, opened and locked while working, enabling easy viewing of   air‑pressure readings

  • •Sturdy stainless‑steel outer casing fitted with a carrying handle.

  • Technical Parameters

  • • •Explosion‑proof certification: ExdI Mb, ExdII BT4Gb
    • •Motor rotational‑speed range: 160‑600 rpm
    • •Read‑out mode: inlet air pressure indicated by built‑in pressure gauge
    • •Speed adjustment: infinitely‑variable speed via air‑flow‑valve tuning
    • •Available controls: start‑stop and rotation‑direction switching operated by the pneumatic directional valve
    • •Rated operating air‑pressure: 0.5 MPa
    • •Air consumption: maximum 4.5 L/s
    • •Ambient operating conditions: 0‑40℃, relative humidity below 80%
    • •Ingress‑protection class: IP31
    • •Driver unit outer dimension (Length × Width × Height): 417 × 250 × 316 mm
