Should you have price for peristaltic pumps required, please feel free to contact us.

DG
Pump Head
DG
DG series pump heads are designed for micro flow rates, multi-channel   fluids transfer and supply high precision. Easy to change and fix the   tubing. The trigger and ratchet wheel have been improved to have better   function. Users can fix and change tubing easily.
CONTACT US
CHARACTER
TECHNICAL PARAMETERS

Character:


  • Occlusion can be adjusted slightly by ratchet wheel to fit different tubing wall thicknesses requirements.

  • 6-rollers pump head supply more flow rate.

  • 10-rollers reduce pulse and flow rates slightly.

  • Skillful trigger structure, convenient to eject the cartridges (DG-1, DG-2)

  • Rollers are made from 304 stainless steel, can resistant acid, soda and organic solvent

  • Cartridges are made from POM or PVDF











Technical Parameters


ModelRollers NO.Available tubingMax flow rate（ml/min）Speed range（rpm）Cartridge material
DG-1A Refers to 6 rollers
       B refers to 10 rollers		ID≤3.17mm；wall thickness 0.8-1.0mmA：48
       B：32		≤100POM  PVDF
DG-2
DG-4
DG-6
DG-8
DG-10
DG-12
