KZ35
Pump Head
KZ35
KZ35 pump head is made from 304 stainless steel fully. It is   specially designed and produced for pharmaceutical and food industry   according to GMP criteria. Also has the characteristics of large flow,   stable and reliable operation, corrosion resistance, at the same time   according to user’s needs, pump heads can be stacked.
CONTACT US
CHARACTER
TECHNICAL PARAMETERS

Character :


  • Accept 73# or 82# tubing, supply wide range flow rate.

  • Can stack two pump heads

  • The benefit of using clamper assembly: use the tubing without   fittings, can meet the health level requirement of No  residual  fluid

  • The benefit of using tubing fittings: outside of the pump head can adopt other tubing which is low cost




Technical parameters ：


ModelShaft typeRollers NO.Rollers materialcasing materialSpeed range（rpm）Available tubingMax flow rate（ml/min）Weight（kg）
KZ35-1ALong shaft Short shaft3Stainless steelStainless steel≤60073#、82#110003.7
