●Technical parameters

•Max stroke: 140mm. Number of channels: 1/2

• •Stroke resolution: 0.156 μm. stroke control precision: Error ≤ ±0.5% (when the stroke is ≥ 30% of the maximum stroke)
• •Linear velocity range: 5 μm/min‑130mm/min (Flow rate=linear speed × inner section of syringe)
• •Linear speed adjustment resolution: 5 μm/min, rated linear thrust: 30kgf
• •Syringe selection: Main manufacturers and models of syringes are available for selection. Can directly input the inner diameter of the syringe
• •Five working modes: infusion/withdrawal,infusion before withdraw,withdraw before infusion,continuous work
• •Power off memory: After power on again, you can choose whether to continue according to the status before the power off
• •Jam protection: When the pump is blocked during operation, the pump will stop and sound a horn alarm
• •The RS485 communication bus can be connected to the upper computer and controlled through backend software.
• •Status signal output: 2‑way OC gate signal output, to indicate start/stop and cw/ccw status
• •Control signal input: 2‑way start/stop control input terminal, 1‑way falling edge trigger signal control start/stop; 1‑way TTL level signal to control start/stop
• •Measurement: 280 × 250 × 140 (mm)
• •Power supply: AC 196V‑240V/40W
• •Working environment temperature 0‑40 ℃
• •Relative humidity ＜ 80%

• •Weight: 4.2kg

•
